Feasures
 Suitable for on-site rapid friction torque comparison and measurement of bearings
Automatic programming test, convenient and fast
Multiple measurement modes (real-time, peak, first peak, mean)
TFT-LCD touch pad, digital and curve dual display
Tolerance alarm, intelligent quality monitoring
Fast calibration, no need to disassemble the sensor
|
 |
Specifications
| Measuring Range |
1.0 N.mm ~ 500.0 N.mm |
| Resolution |
0.1 N.mm |
| Accuracy |
0.5%±2LSB |
| Units |
N.mm, N.cm, Kgf.cm, Lb.in |
| Display |
7" TFT-LCD, touchpad |
| Overload |
200% |
| Measurement Mode |
Real, Peak, First Peak, Mean |
| Rotary Drive |
Brushless DC motor |
| Rotary Speed |
80 ~ 600 r/min |
| Power |
24V DC |
| Output Interface |
USB |
| Dimensions |
700X500X500 mm |
| Net Weight |
38 kg |
|
|
